Technical data
Operating principle: Hazer without compressor
Connection data: 100-240 V~, 50-60 Hz, 500 W (PowerCON TRUE1)
Heating time: 5 seconds
Haze density: 1-100% adjustable
Fluid tank: 1000ml
Pump capacity.1% pump capacity 5.6ml / hr. 100% pump capacity 223ml / hr.
Operation: 2.8″ TFT display with touch panel, automatic display rotation (0° / 180°)
Communication interfaces: 10/100 Mbit Ethernet with integrated 2-port switch. 5 pin XLR in/out
Supported protocols: Artnet, sACN, DMX512, RDM
DMX control: 3 channels (pump, fan speed, angle )
Integrated fans: 2 axial fans with one per 100m³/h, 0-100 adjustable,
Air leading metal: 2 motorized controllable air leading metals, +/- 45 ° swiveling
Integrated sensors
Fan speed, accelerometer, temperature sensor
